TONSON Air Winches
TONSON Air Winches for lifting and pulling in
Offshore Applications or in Hazardous Environments
(offshore, flammable, volatile, humid, dust, high temperature)

Capacity: 5, 10, 20, 50, 100 kN

Standard Features:
*Rotary vane air motor or radial piston
  air motor
*Steel drum (not grooved) with cable   fixing point at flange
*Two drum supports
*Working temperature of -10 to 45   degree Celsius

Winch Options:
*Alternative drum lengths
*Pressure Roller
*Drum guard
*Drum Divider Flange

Control Options:
*Proportional remote control valve
*Air service units
air winch by TONSON



SPECIFICATIONS
Model
AK0.5T
AK1T
AK2T
AK5T
AK10T
   Line Pull (kN)
5
10
20
50
100
   Ratio
36.6
40.59
54.9
132.35
200.8
   Drum Diameter
165 x 350
165 x 400
219 x 535
325 x 640
500 x 1000
   Drum Speed (RPM)
38.8
35.47
26.23
8.1
4.8
   Rope DIA. | Max Rope DIA. (mm)
50 | 100
70 | 160
80 | 180
0 | 200
0 | 300
   Rope Spec
6 x 19
6 x 19
6 x 19
6 x 19
6 x 37
   Rope DIA. (mm)
7.7
9.3
12.5
19.5
30
   Lifting Speed (m/min)
22
22
22
9
9
   Dimension (L x W x H)
710 x 620 x 340
750 x 740 x 400
980 x 880 x 530
1310 x 1140 x 800
1900 x 1650 x 890
   Mass (kg)
110
200
400
780
2000
Specifications are subject to change without notice.
